Inoxpa HYGINOX SE Hygienic Centrifugal Pump

The HYGINOX SE hygienic pump manufactured by Inoxpa is a centrifugal pump which is a cost efficient and reliable pumping solution. Thanks to its hygienic design, this sanitary centrifugal pump is designed for the brewing, dairy, beverage, pharmaceutical and cosmetic industries, where a hygienic pump is required to prevent contamination of the pumped fluid and ensure a safe transfer. To ensure long life, any pump parts in contact with the pumped media are manufactured from corrosion resistant AISI 316 stainless steel. The complete sanitary centrifugal pump has a cold-formed stainless steel casing and a stainless steel open impeller (investment casting), mechanical seal, pump cover, lantern and shaft, connected to the motor by mechanical compression. This makes it a perfect pumping solution application that requires the utmost levels of cleanliness. In addition, HYGINOX SE stainless steel sanitary pumps are meticulously manufactured to ensure reliable, long-lasting operation as well as provide easy cleaning and maintenance. The beauty of the HYGINOX SE hygienic centrifugal pump is that it can be dismantled with ease for easy and efficient cleaning.

The Inoxpa pump motor is also protected with a stainless-steel shroud and provided with height-adjustable legs for enhanced functionality. This hygienic centrifugal pump comes with an internal single mechanical seal with a hygienic design. As standard, the stationary part is in carbon, the rotary part is in silicon carbide, and the gaskets are in EPDM. However, the HYGINOX SE sanitary pump can be supplied with other materials compatible with pumped fluid when required.

Specifications
►Maximum flow rate: Up to 140 m³/h
►Maximum liquid temperature: 120°C (as standard, please specify if pumping anything at a higher temperature)
►Maximum operating pressure: 10 bar
►IP55, class F insulation

Materials
►Parts in contact with media: AISI 316 stainless steel
►Other steel parts: AISI 304 stainless steel
►Gaskets: EPDM

Due to the complexity and quantity of HYGINOX SE hygienic centrifugal pump models available, we recommend that you call us on 01777 871100 to discuss your requirements with one of our technical engineers. Upon request, ATEX hygienic pumps are also available.
